Ortofon 2M 78

Ortofon 2M 78 - Platenspeler element

149,-

stuk
Bestelbaar
Bekijk winkelvoorraad

Winkelvoorraad

Ortofon 2M 78

Ortofon 2M 78

 149,-

iEar' | Tilburg

st. Ceciliastraat 28,
5038 HA Tilburg

4 tot 20 dagen levertijd

iEar' | Amsterdam

Beethovenstraat 9-b,
1077 HL Amsterdam

4 tot 20 dagen levertijd

Verlanglijst

Heb je al een iEar' account? Log dan in of maak een account aan om producten aan je verlanglijst toe te voegen.

Registreren

Je persoonlijke gegevens worden gebruikt om je ervaring op deze site te ondersteunen, om toegang tot je account te beheren en voor andere doeleinden zoals omschreven in onze privacybeleid.

Omschrijving

Ortofon 2M 78 Element
MM element (Moving Magnet)
2M Series


The 2M Series of cartridges is designed for precise and accurate retrieval of the information in the record groove. Our philosophy is to play the record sound as accurate as possible, without coloring the sound. The name 2M was selected among several ideas. We wanted a modern name that would be easy to pronounce and to remember, and therefore an alpha numerical name was chosen. 2M means MM, which is the abbreviation for moving magnet. The 2M series of cartridges feature Ortofon’s trademark split pole pins, an invention that enables moving magnet cartridges to have a flat frequency response, as with a moving coil cartridge. Split pole pins were invented by Ortofon, and were originally presented in the 500 series and Super OM series. We have optimized the design for ease of mounting the cartridge, weight and size to fit the most common turntables at the market today. 2M Series provides excellent compatibility in an assortment of playback systems and with a wide variety of phono preamps.

Specifications
• Output voltage at 1000 Hz, 5cm/sec. 4 mV
• Channel balance at 1 kHz
• Channel separation at 1 kHz
• Channel separation at 15 kHz
• Frequency range at – 3dB 20-20.000 Hz
• Frequency response 20-20.000 Hz + 3 / – 1 dB
• Tracking ability at 315Hz at recommended tracking force 70 µm
• Compliance, dynamic, lateral 18 µm/mN
• Stylus type Spherical
• Stylus tip radius R 65 µm
• Tracking force range 1,6-2,0g (16-20 mN)
• Tracking force, recommended 1,8 g (18 mN)
• Tracking angle 20°
• Internal impedance, DC resistance 700 Ohm
• Internal inductance 300 mH
• Recommended load resistance 47 kOhm
• Recommended load capacitance 150-300 pF
• Cartridge colour, body/stylus Black/Grey
• Cartridge weight without screws 7,2 g
• Replacement stylus unit 2M 78
• Stylus protection guard 2M 78

Specificaties

Algemeen

Type element
MM (moving magnet)
Serie
2M serie
Kwaliteitsklasse
Basis klasse

Techniek

Naald vorm
sferisch
Naald materiaal
tipped diamond
Cantilever
aluminium
Body
Kunststof
Frequentiebereik
20 - 20.000 Hz
Weerstand
700 Ohm
Output
High output
Output voltage
4,0 mV
Naalddruk
1,6 - 2,0 gram
Kanalen
Stereo (2 kanalen)
Kanaalscheiding
mono
Montage
excl. headshell

Fysieke eigenschappen

Uitvoering
zilver/zwart
Gewicht
7,2 gram

SKU

EAN
5705796080063
